Main
Range of product
Altivo
Product or component type
Switch
Device presentation
Complete mechanism
Device mounting
Flush
Number of gangs
1 gang
Device application
Light control
Colour tint
White
Complementary
Switch function
1-way
Rated current
10 A
[Ue] rated operational voltage
250 V
Network type
AC
Network frequency
50 Hz
Number of modules
1 module
Actuator
Rocker
Material
PC (polycarbonate)
Contacts material
Copper
Connections - terminals
Screw terminals
Type of installation
Indoor
Width
86 mm
Height
88 mm
Environment
Ambient air temperature for operation
-5…40 °C
Relative humidity
0…95 %
IP degree of protection
IPx0
Standards
IEC 60669-1
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Contractual warranty
Warranty
120 months
