Residual Current Operated Circuit Breaker, HDB3LE, 2P, C curve, 50A, 30mA, AC
Дифференциал автомат #HDB3LE2C50
Actions
Price section
Үнэ/ 1 ш
24,200 ₮
Buy section
Тоо хэмжээ:
- Фазын тоо
- 2P
- Нэрлэсэн гүйдэл /А/
- 50
- Curve code
- C
- Дифференциал гүйдэл
- 30mA
Main
Range of product
HDB3LE
Product or component type
Residual current breaker with overcurrent protection (RCBO)
Mechanical durability
20000 cycles
[In] rated current
50 A
Electrical durability
10000 cycles
Trip unit technology
Thermal-magnetic
Device application
Isolation
Complementary
Poles description
2P
[In] rated current
50 A
Earth-leakage sensitivity
30.0 mA
[Ue] rated operational voltage
230 V AC 50...60 Hz
Residual current
30 mA
[Uimp] rated impulse withstand voltage
4.0 kV
Curve code
C
Magnetic tripping limit
5...10 x In
Cable entry
Top and bottom
Mounting support
35 mm DIN rail
Clamping connection capacity
<= 25 mm²
Tightening torque
2.5…4.5 N.m
Connections - terminals
Forked type tag connectors
Environment
Tropicalisation
2
IP degree of protection
IP20
Electrical shock protection class
Class II
Ambient air temperature for operation
-35…70 °C
Standards
IEC 61009-1
Product certifications
CE
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Contractual warranty
Warranty
18 months
