Miniature circuit breaker, HDB3w-125, 27 mm, AC, 10 kA, 3P, C curve, 100 A
Модулийн автомат #HDB3W125H3C100
Actions
Price section
Үнэ/ 1 ш
46,200 ₮
Buy section
Тоо хэмжээ:
- Фазын тоо
- 3P
- Нэрлэсэн гүйдэл /А/
- 100
- Curve code
- C
- Таслах чадал
- 10kA
Main
Range of product
HDB3w-125
Product or component type
Miniature circuit-breaker
Device application
Isolation
Trip unit technology
Thermal-magnetic
Suitability for isolation
Yes
Mechanical durability
8500.0 cycles
Electrical durability
1500.0 cycles
Complementary
Poles description
3P
[In] rated current
100 A
[Ue] rated operational voltage
400 V AC 50/60 Hz
Curve code
C
Magnetic tripping limit
8.5 x In
Breaking capacity
10 kA
[Ui] rated insulation voltage
250.0 V between phase and ground
500.0 V between phases
500.0 V between phases
[Uimp] rated impulse withstand voltage
4.0 kV
Cable entry
Top
Bottom
Bottom
Mounting support
35 mm DIN rail
Protection type
Overload protection
Short-circuit protection
Short-circuit protection
Connections - terminals
Forked type tag connectors
Clamping connection capacity
<= 50 mm²
Tightening torque
3.5 N.m
Height
86.4 mm
Width
81.0 mm
Depth
77.5 mm
Embedding depth
44.0 mm
E-commerce address
Hdb3w-125-mcb-27mm-up-to-125a-10ka-breaking-capacity-1
Environment
Dielectric test voltage
2.0 kV 50/60 Hz 1 min
Shock resistance
30 gn (duration = 11.0 ms) for 3 shocks
Standards
IEC 60947-2
IP degree of protection
IP20
Pollution degree
2
Ambient air temperature for operation
-20…60 °C
Ambient air temperature for storage
-40…70 °C
